Specs
| Model | Deck Width | Engine | Horsepower | MSRP |
|---|---|---|---|---|
| STCII-48V-22FX | 48″ | Kawasaki® FX Series | 22 | $12,819 |
STCII-48V-23CV  | 48″ | Kohler® Command PRO® | 23 | $11,729 |
| STCII-52V-25CV-EFI | 52″ | Kohler® Command PRO® EFI – electronic fuel injection | 25 | $12,599 |
| STCII-52V-26FT-EFI | 52″ | Kawasaki® FT Series – electronic fuel injection | 26 | $13,399 |
| STCII-52V-28BV-EFI | 52″ | Vanguard™ EFI – electronic fuel injection | 28 | $13,119 |
STCII-52V-36BV  | 52″ | Vanguard™ BIG BLOCK™ | 36 | $14,179 |
| STCII-61V-26CV-EFI | 61″ | Kohler® Command PRO® EFI – electronic fuel injection | 26 | $13,499 |
| STCII-61V-26FT-EFI | 61″ | Kawasaki® FT Series EFI – electronic fuel injection | 26 | $13,779 |
| STCII-61V-36BV | 61″ | Vanguard™ BIG BLOCK™ | 36 | $14,349 |
| Contact your local Scag dealer for specific availability information. | ||||
| General | |
|---|---|
| Total Fuel Capacity | 9.5 gallons |
| Drive Tires | 24″ x 9.5″-12″ (48″ and 52″) 24″ x 12″-12″ (61″) |
| Caster Tires | 13″ x 6.5″-6″, flat-free |
| Seat | 4-point iso-mounted mid-back mounted on operator-suspension platform |
| Drive System | |
| Drive System Type | Dual Pump and Motor |
| Pumps | Hydro-Gear 12 cc |
| Motors | Parker 14.5 ci |
| Forward Ground Speed | 12 mph |
| Reverse Ground Speed | 5 mph |
| Parking Brake | Foot-operated pedal |
| Deck | |
| Cutting Widths | 48″, 52″ and 61″ |
| Type | Velocity Plus™ |
| Cutting Height | 1″ to 5″ in .25″ increments |
| Deck Lift | Adjustable foot-operated pedal |
| Construction | Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2″ of steel. Reinforcement plates at cutter deck spindles. |
| Spindles | Cast-iron housing with tapered roller bearings. |
| Blade Engagement | Adjustable air-gap for extended life. |
